Heat Recovery Type VR-II Series AOUA144TLCVG [3Phase]
Features
- High Operating Energy Efficiency
- Space saving combination
- Energy efficiency combination
- All inverter compressor
- Ideal heat exchanger path control
- Sophisticated operation control
- Flexible piping connection
- Flexible installation of Refrigerant Branch unit
Capacity
144,000 BTU/h
162,000 BTU/h
Specification
| Rating Capacity Range | 12 |
|---|---|
| Maximum Connectable Indoor Unit | 22 |
Scroll
| Power source | Phase | 3-phase |
|---|---|---|
| Voltage | 460 V | |
| Frequency | 60 Hz | |
| Capacity | Cooling | 144,000 BTU/h |
| 42.2 kW | ||
| Heating | 162,000 BTU/h | |
| 47.5 kW | ||
| Input Power | Cooling | 11.69 kW |
| Heating | 12.73 kW | |
| EER (Non-Ducted/Ducted) | Cooling | 11.4 / 11.4 Btu/hW |
| IEER (Non-Ducted/Ducted) | Cooling | 22.2 / 20.4 Btu/hW |
| COP (Non-Ducted/Ducted) | Heating | 3.44 / 3.44 W/W |
| SCHE (Non-Ducted/Ducted) | 22.2 / 22.2 Btu/hW | |
| Air Flow Rate | 2×6,533 CFM (2×11,100 m³/h) | |
| Sound Pressure Level | Cooling | 60 dB(A) |
| Heating | 61 dB(A) | |
| Maximum external static pressure | 0.32 in.WG (80 Pa) | |
| Compressor motor output | 2×7.5 kW | |
| Net Dimensions | Height | 66-9/16 inch (1,690 mm) |
| Width | 2×(36-5/8) inch (2×930 mm) | |
| Depth | 30-1/8 inch (765 mm) | |
| Net Weight | 2×597 lbs (2×271 kg) | |
| Refrigerant | Type | R410A |
| Charge | 2×26.01 lbs (2×11.8 kg) | |
| Connection Pipe Diameter | Liquid | 1/2 inch (12.70 mm) |
| Discharge Gas | 7/8 inch (22.22 mm) | |
| Suction Gas | 1-1/8 inch (28.58 mm) | |
| Operation Range | Cooling | 14 to 115 °FDB (-10 to 46 °CDB) |
| Heating | -4 to 70 °FDB (-20 to 21 °CDB) | |
Scroll
- Note :
- Specifications are based on the following conditions.
- Cooling :
- Indoor temperature of 80°F (26.7°C) DB / 67°F (19.4°C) WB, and outdoor temperature of 95°F (35.0°C) DB / 75°F (23.9°C) WB.
- Heating :
- Indoor temperature of 70°F (21.1°C) DB / 60°F (15.6°C) WB, and outdoor temperature of 47°F (8.3°C) DB / 43°F (6.1°C) WB.
- Pipe length :
- 25ft. (7.5 m); Height difference between outdoor unit and indoor unit : 0ft. (0 m).
- *1
- Electrical data is only for outdoor unit.
Dimensions
Outdoor Unit : AOUA144TLCVG
