AIRSTAGE SINGLE-ROOM MINI-SPLIT SYSTEMS Floor Mounted RLFFH Series Floor Mounted / RLFFH (-15°F Heating) 15RLFFH

XLTH; Extra Low Temperature Heating

Indoor Unit Systems: AGU15RLF, Outdoor Unit: AOU15RLFFH

Indoor Unit:
AGU15RLF
Outdoor Unit:
AOU15RLFFH
Downloads:
Operation Manual
Warranty
Up to 26 SEER
  • INVERTER 7 year compressor 5year parts Warranty. Refrigerant R410A ENERGY STAR®

Features

  • Compact Size
  • Energy Efficient
  • 2-Fan and Wide Airflow
  • High Performance Heating
  • Flexible and Easy Installation

Sleep Timer: Automatically adjusts the temperature while you sleep to make you more comfortable. Auto Louver: Up/Down: Redirects airflow automatically with seven position up and down motion which can be set to auto swing. Automatic air flow adjustment: The micro-computer automatically adjusts the air flow effectively to follow the changes of room temperature. 24 Hour Timer: Allows for one on/off cycle during a 24 hour period. Economy Mode: Thermostat setting automatically changes according to the temperature to avoid unnecessary cooling and heating. Auto Restart/Reset: Following a power failure, systems will automatically restart in the same operating mode as before, once power has been restored. Auto restart: In the event of a temporary power failure, the air conditioner will automatically restart in the same operating mode as before, once the power supply is restored. Low Ambient Cooling: Can operate in cooling mode even when outdoor ambient is 0°F, 14°F or 32°F, depending on model, without modification. Operation outside of factory specification is not recommended. Apple Catechin Filter (polyphenol ingredient from apples): Dust, mold spores and microorganisms are absorbed onto the filter by static electricity and growth is inhibited and deactivated. 3 - 12 month life expectancy, depending on environment. Ion Deodorizing Filter: Deodorizes by decomposing absorbed odors using the oxidizing and reducing effects of ions generated by fine ceramic particles. 3 year life expectancy. Wash to restore surface action. Minimum Heat Mode: Sets room temperature to 50°F, keeping temperatures above freezing and reducing power consumption. Powerful Operation: 20 minutes of continuous operation at maximum airflow and maximum compressor speed. Rapid cooling and heating makes the room comfortable quickly.

Cooling  14,200 BTU/h
Heating  18,000 BTU/h
Specification
Power Source Voltage/Frequency/Phase 208-230/60/1
Capacity Cooling BTU/h 14,200(3,100~17,700)
Heating 18,000(3,100~20,800)
HSPF BTU/hW 11.0
SEER BTU/hW 20.3
EER Cooling/Heating W/W 12.5/11.3
Operation Range Cooling °F(°C) 14~115 (-10~46)
Heating -15~75 (-26~24)
Moisture Removal Pt./h(l/h) 4.44 (2.1)
MAX.CRT.BKR A 20
Air Circ. C.F.M. Hi (m³/h) 383 (650)
Medium 306 (520)
Low 235 (400)
Quiet 159 (270)
Noise Level Hi dB(A)
15RLS3		 44/43
Medium 38/37
Low 31/29
Quiet 23/23
Outdoor Fan Speed RPM 1,050/1,000
Outdoor Noise Level dB(A)
Clg/Htg		 54/54
Current Cooling A 5.1
Heating 7.0
Power Use Cooling kw 1.13
Heating 1.58
Fan Speeds Stage 4+Auto
Air Direction Horizontal Manual
Vertical Automatic
Air Filter Washable
Apple Catechin Filter Yes
Ion Deoderizing Filter Yes
Connection Method Flare
Combined Min.Lgth Ft (m) 10 (3)
Max.Lgth 66 (20)
(pre-charge: 49’)
Max. Vertical Diff. Ft (m) 49 (15)
Conn. Pipe Diameter Indoor Inch Suc. 1/2
Outdoor Dis. 1/4
Net Weight Indoor lbs.(kg) 31 (14)
Outdoor 88 (40)
Dimensions Height Indoor Inch 23-5/8
mm 600
Outdoor Inch 24-7/16
mm 620
Width Indoor Inch 29-1/8
mm 740
Outdoor Inch 31-1/8
mm 790
Depth Indoor Inch 7-7/8
mm 200
Outdoor Inch 11-7/16
mm 290
Refrigerant (Global Warming Potential) R410A
Scroll
Dimensions

Indoor Unit: AGU15RLF

Indoor Units: Dimensions

Outdoor Unit: AOU15RLFFH

Outdoor Units: Dimensions
