PRESS RELEASE

April 17, 2003
Fujitsu General Limited
(NO.03-N01-04)

Strengthening Product Line-up of Inverter Type Air Conditioners for Overseas Market

New release of 5 types of inverter air conditioners
developed with our original energy-saving technology as a core

We will start selling 5 types of new products ranging from small split type to large multi type of inverter air conditioners from this May for overseas market developed with our original energy-saving technology as a core aiming to strengthen the product line-up and expand sales.

Inverter type air conditioners aim at realizing the enhancement of comfortable air conditioning and excellent energy-saving performance by such features as quick starting-up and smooth temperature control are the products developed in Japan. More than 90% of room air conditioners sold in Japan are of inverter type, but inverter type accounts for only about 10% of all room air conditioners yet in overseas markets. Although non-inverter type is main yet, people's attention for inverter type is increasing more and more, and the demand is steadily growing because of increasing needs for comfortable air conditioning and energy saving due to environmental issue in various countries. (125% compared with previous year, according to our company's survey)

We have started the development of inverter air conditioners in Japan at an early stage tackling the pursuit of comfortable air conditioning and energy-saving performance positively and this time, developed total 5 types, 18 models of indoor and outdoor units ranging from small wall mounted type to multi type making full use of the energy-saving technology and air flow technology accumulated in the past and with our original new form "Ceiling Wall" type as a core. We will aim to strengthen the line-up of inverter air conditioners, and to expand sales in overseas markets where the demand is expected to increase.

The small size new form "Ceiling Wall"*1 type air conditioner with core technology of air flow for air-conditioning to be released this time is the most advanced energy-saving product and will be marketed in overseas markets after released in Japan. It has always kept high energy saving performance, adopting the world's first*2 "Automatic filter cleaning structure", and equipped with "2 wavelength UV*3 pasteurizing lamp" pursuing healthiness as for powerful clean function and "Negative ion" generator refreshing air in the room. Moreover, it is also the high value added product realizing "Rank A" of European energy-saving labeling scheme.

4 other types are also realizing comfortable air conditioning and excellent energy-saving performance by such functions as quick starting-up and smooth temperature control.

Line-up of new products (inverter air conditioners)

  1. New form "Ceiling Wall" type pursuing air flow technology of air conditioning
    Photo: AWY14/17LSAC(Left), AWT24/30PBA(Right)
  2. Small size wall mounted split type compatible with "Rank A" of European energy saving labeling scheme: ASY9/12LSAC

    Photo: ASY9/12LSAC

  3. 3HP 4 room multi type excelling in cost performance
    Photo: ASY9/12VMN+etc (Left), ASY9/12QMA+etc (Right)

Features of new form "Ceiling Wall" type

New form "Ceiling Wall" type pursuing air flow technology of air conditioning

1) Small size new form "Ceiling Wall" type

Photo: Ceiling Wall type

  1. Considerable improvement of heating and cooling effect and energy saving operation through ideal "air flow"
    - "Powerful vertical air flow", "Healthy horizontal air flow" and "Rank A" compatibility with European energy saving labeling scheme
  2. Automating troublesome cleaning of filter while maintaining high energy saving operation
    - The world's first "automatic filter cleaning structure"
  3. Powerful cleaning function pursuing healthiness
    - The world's first "2 wavelength UV pasteurizing lamp"
    "UV room air clean" and "UV inside air clean" which pasteurize and deodorize the room air and the air inside the equipment
    - "Negative ion" generator refreshing air in the room
    It is equipped with negative ion generator, effectively spreading about 40,000pcs/cc *4 (at the center of the room) of "negative ions" to the whole room.

Automatic filter cleaning structure


2) Large size new form "Ceiling Wall" type

Large size new form "Ceiling Wall"type

  1. Realizing heating and cooling effect through ideal "air flow" and big capacity
    - Adopting "High efficient DC twin rotary compressor", "PAM control"
    Realizing big capacity: "8.0kW (27,300BTU), highest in 24 class and 8.5kW (29,000BTU), highest in 30 class"
    "Powerful vertical air flow" and "healthy horizontal air flow" through "Independent variable large size power diffuser"
  2. Improvement of installation and maintenance performance
    - "Long piping connection (30m)"
    - Adopting "Detachable and washable drain pan", "Long-life filter"
  3. Enhancement of convenience
    - Our original "4-step switching function of maximum operation current"
    - "Auto restart function

Features of small size wall mounted split air conditioner

ASY9/12LSAC

  1. Top class energy saving
    - Indicating "Rank A" of European energy saving labeling scheme
  2. "Easy opening panel (with double doors opening outward)" and "detachable top grille" useful for easy cleaning and energy saving
  3. "Inside drying" function keeping the inside of indoor unit clean

Features of 3 HP 4 room multi type

1) Cooling only multi air conditioner for Southeast Asia excelling in cost performance

ASY9/12VMN , ASY18/24VMN , AOY36VMNM4

  1. Realizing top class efficiency, high capacity
    - "High efficiency DC twin rotary compressor", "PAM control", "Maximum capacity 10.0kW (34,000BTU)"
  2. Enhancement of convenience
    - Our original "4-step switching function of maximum operation current"
    - "Compact outdoor unit of 70cm in height suitable for housing conditions in Singapore
    - Combination of indoor units selectable from 4 models (9/12/18/24,000BTU)
    - "Auto restart function"
  3. Improvement of installation performance
    - "Long piping connection (up to 70m) without additional refrigerant charging"

2) Heat pump multi type

ASY9/12QMA , ASY18/24QMA , AOY30QMAM4

  1. Realizing top class efficiency, high capacity
    - "High efficiency DC twin rotary compressor", "PAM control", "Maximum capacity cooling 9.5kW(32,400BTU), heating 11.2kW(38,200BTU)"
  2. Enhancement of convenience
    - Our original "4-step switching function of maximum operation current"
    - Combination of indoor units selectable from 4 models (9/12/18/24,000BTU)
    - "Auto restart function"
  3. Improvement of installation performance
    - "Long piping connection (up to 60m) without additional refrigerant charging"

Sales projection

  2003 2004 2005
Small size "Ceiling Wall" type 6,000 sets 20,000 sets 40,000 sets
Large size "Ceiling Wall" type 6,000 sets 16,000 sets 30,000 sets
Small wall mounted type 60,000 sets 120,000 sets 200,000 sets
3HP cooling only 4 room multi type 6,000 sets 10,000 sets 16,000 sets
3HP heat pump 4 room multi type 6,000 sets 12,000 sets 20,000 sets

Main specifications

Small size "Ceiling Wall" type

Indoor unit AWY14LSACW AWY17LSACW
Outdoor unit AOY14LSA AOY17LSA
Cooling Rated capacity BTU 13,600 16,400
kW 4.0 4.8
COP W/W 4.0 3.29
Capacity range BTU 3,100 - 18,100 3,100 - 20,100
kW 0.9 - 5.3 0.9 - 5.9
Heating Rated capacity BTU 20,500 22,900
kW 6.0 6.7
COP W/W 4.35 4.09
Capacity range BTU 3,100 - 28,700 3,100 - 31,400
kW 0.9 - 8.4 0.9 - 9.2
Noise level Indoor unit dB(A) 31 - 47 (Quiet-Hi) 31 - 49 (Quiet-Hi)
Outdoor unit dB(A) 47 49
External
dimension
Indoor unit H × W × D(cm) 25 × 89 × 28.8 25 × 89 × 28.8
Outdoor unit H × W × D(cm) 57.8 × 79 × 30 57.8 × 79 × 30

Large size "Ceiling Wall" type

Indoor unit AWT24PBA AWT30PBA
Outdoor unit AOT24PMAL AOT30PMAL
Cooling Rated capacity BTU 24,200 27,300
kW 7.1 8.0
COP W/W 2.70 2.42
Capacity range BTU 4,800 - 27,300 4,800 - 29,000
kW 1.4 - 8.0 1.4 - 8.5
Heating Rated capacity BTU 29,000 32,400
kW 8.5 9.5
COP W/W 3.10 2.86
Capacity range BTU 4,800 - 32,400 4,800 - 34,800
kW 1.4 - 9.5 1.4 - 10.2
Noise level Indoor unit dB(A) 37 - 45 (Quiet-Hi) 37 - 45 (Quiet-Hi)
Outdoor unit dB(A) 47 - 52 (Quiet-Hi) 47 - 52 (Quiet-Hi)
External
dimension
Indoor unit H × W × D(cm) 27 × 115 × 28.5 27 × 115 × 28.5
Outdoor unit H × W × D(cm) 90 × 90 × 35 90 × 90 × 35

Small wall mounted type

Indoor unit ASY9LSACW ASY12LSACW
Outdoor unit AOY9LSAC AOY12LSAC
Cooling Rated capacity BTU 8,900 11,900
kW 2.6 3.5
COP W/W 3.82 3.40
Capacity range BTU 1,700 - 12,300 3,100 - 14,300
kW 0.5 - 3.6 0.9 - 4.2
Heating Rated capacity BTU 2,300 16,400
kW 3.6 4.8
COP W/W 3.96 3.61
Capacity range BTU 1,700 - 20,500 3,100 - 22,500
kW 0.5 - 6.0 0.9 - 6.6
Noise level Indoor unit dB(A) 26-42 (Quiet-Hi) 29-43 (Quiet-Hi)
Outdoor unit dB(A) 49 49
External
dimension
Indoor unit H × W × D(cm) 28 × 79 × 23 28 × 79 × 23
Outdoor unit H × W × D(cm) 53.5 × 78 × 25 53.5 × 78 × 25

3HP cooling only 4 room multi type

Indoor unit 4 sets (24 + 12 + 12 + 12)
Outdoor unit AOY36VMNM4
Cooling Rated capacity BTU 31,400 (12,000 + 6,500 × 3)
kW 9.2 (3.5 + 1.9 × 3)
COP W/W 3.01
Capacity range BTU 13,600 - 34,100
kW 4.0 - 10.0
Noise level Indoor unit dB(A) 24 : 34 - 45 (Quiet-Hi)
12 : 33 - 39 (Quiet-Hi)
Outdoor unit dB(A) 47 - 52 (Quiet-Hi)
External
dimension
Indoor unit H × W × D(cm) 24 : 32 × 112 × 22
12 : 26 × 81.5 × 17.5
Outdoor unit H × W × D(cm) 70 × 90 × 35

3HP heat pump 4 room multi type

Indoor unit 4 sets (18 + 9 + 9 + 9)
Outdoor unit AOY30QMAM4
Cooling Rated capacity BTU 27,300 (11,000 + 5,500 × 3)
kW 8.0 (3.2 + 1.6 × 3)
COP W/W 3.02
Capacity range BTU 14,000 - 32,400
kW 4.1-9.5
Heating Rated capacity BTU 32,800 (13,300 + 6,500 × 3)
kW 9.6 (3.9 + 1.9 × 3)
COP W/W 3.58
Capacity range BTU 14,000 - 38,200
kW 4.1-11.2
Noise level Indoor unit dB(A) 18 : 32 - 42 (Quiet-Hi)
9 : 32 - 38 (Quiet-Hi)
Outdoor unit dB(A) 47 - 52 (Quiet-Hi)
External
dimension
Indoor unit H × W × D(cm) 18 : 32 × 112 × 22
9 : 26 × 81.5 × 17.5
Outdoor unit H × W × D(cm) 90 × 90 × 35

Note

*1 The small size new form "Ceiling Wall" :
Now being sold in Japan with name of "nocria".
*2 the world'sfirst :
as of April, 2003, according to our company's survey.
*3 UV :
Ultraviolet
*4 about 40,000pcs/cc :
When operating in "comfortable dehumidification" condition of the outside temperature 27°C and humidity 80%. In our environmental test room about 13m². 60cm in height at the center of the room.
*
"Design", "Automatic cleaning filter", "UV pasteurizing", "Diffuser": Patent Pending
