Halcyon™ SINGLE-ROOM MINI-SPLIT SYSTEMS Cassette

Halcyon™
Indoor Unit Systems: 18RCLX, 24RCLX, 36RCLX, 42RCLX

Model

Cooling17,800 BTU/h
Heating21,000 BTU/h
18RCLX
Cooling22,200 BTU/h
Heating24,200 BTU/h
24RCLX
Cooling34,100 BTU/h
Heating36,000 BTU/h
36RCLX
Cooling42,700 BTU/h
Heating45,200 BTU/h
42RCLX

Features

Extremely discreet, with only the grill showing in the ceiling.

Latest fan technology distributes the conditioned air evenly throughout the room. Ceiling cassette systems provide both heating and cooling and are popular in commercial applications such as offices, conference rooms, restaurants, night clubs and bars, as well as new construction condominiums and homes.

Inverter Technology

Through new, advanced technology, Inverter air conditioners are more economical to operate and quieter to run than conventional units. They can handle greater extremes in temperature, are smoother and more stable in operation, and reach the desired temperature faster than conventional air conditioners.

Swing Louvers

The airflow direction, up or down is set automatically to match the operating mode, down for heating, up for cooling.

Swing Louvers

The airflow direction, up or down is set automatically to match the operating mode, down for heating, up for cooling.

4-Way Airflow System

Airflow in all directions maintains an even temperature throughout a space, perfect for corner installations or in long hallways.

Simple Maintenance

Detachable and washable air intake grille and filter

Wired Remote Controller

Features of the standard wired remote controller include:

  • Weekly timer
  • Set different on-off time by day
  • Set on-off time twice a day
  • Set time in 5 minute intervals
  • Child lock capable
  • Remote temperature sensor
  • Set different temperatures throughout the day.

Energy Saver

A room is kept cool by using a relaxed thermostat setting which allows the system to reduce power consumption when a set temperature is reached.

Smart System: Auto Mode

When the system is initially turned on, the fan speed is HIGH to reach the set temperature as quickly as possible. The fan speed will automatically adjust downward as the room begins to reach the set temperature.

Humidity Control

This system features Dry Mode, which helps to control humidity levels, even when cooling may not be needed.

Fresh Air Intake

Outside air can be introduced by attaching field supplied flexible duct to fresh air knockouts.

Other Standard Features Include:

Auto Restart/Reset: Following a power failure, systems will automatically restart in the same operating mode as before, once power has been restored.
Auto Restart/Reset
Auto restart: In the event of a temporary power failure, the air conditioner will automatically restart in the same operating mode as before, once the power supply is restored.
Auto Changeover
High Ceiling Mode: Temperature at the top of a high ceiling room may be warmer than the space occupied; this mode adjusts for this difference.
High Ceiling Mode
Cold Prevention: Indoor coil will warm prior to fan operating, preventing cold air during heating mode.
Cold Prevention
Low Ambient Cooling: Can operate in cooling mode even when outdoor ambient is 0°F, 14°F or 32°F, depending on model, without modification. Operation outside of factory specification is not recommended.
Low Ambient
