PRESS RELEASE

April 6,2009
Fujitsu General Limited
(NO.09-N01-02)

Realizing industry's top class^(*1) energy-saving performance New release of home use 2-room multi inverter air conditioner for Europe (Details)

(Indoor unit: ASYA07 / 09 / 12LBCM Outdoor unit: AOYA14LAC2)

Main features

1. Realizing industry's top class^(*1) energy-saving performance

i) Realizing industry's top class^(*1) energy-saving performance COP3.67 (cooling operation) / 4.27 (heating operation)

Compact size is realized by adopting Φ5mm thin diameter copper pipe for high density heat exchanger. Also, by adopting Φ5mm heat exchanger, refrigerant can be provided evenly to heat exchanger and at the same time, by using high efficient DC inverter compressor, industry's top class^(*1) energy-saving performance COP3.67 (cooling operation) / 4.27 (heating operation) has been realized.

High density heat exchanger

ii) Designing new outdoor unit in compact size, same size as outdoor unit of single type of equal capacity

In the new outdoor unit, compact size is realized to the same size as outdoor unit of single type of equal capacity by reviewing refrigeration cycle and structure designing, optimizing piping inside the machine and downsizing compressor and inverter unit. Thus, installation space saving has been realized.

Photo of the outer unit.

2. Improving energy-saving performance and comfort level in actual use

In the new 2-room multi air conditioner, energy-saving performance and comfort level in actual use are improved by room temperature save operation and heating operation even at outside temperature –15°C with adoption of “10°C heat” and “–15°C heating operation” functions.

i) “10°C heat” function to save room temperature when nobody is at home and reduce power consumption

In order to quickly reach the set temperature after returning home, “10°C heat” function to operate with the set temperature at 10°C simply by pressing save button when going out is adopted. Thereby, comfort level is enhanced by controlling the room temperature quickly after returning home as well as reducing power consumption while nobody is at home.
Also, when nobody is at home for a long time, the room temperature can be maintained by “10°C heat” function to prevent furniture from freezing.

Remote controller with “10°C heat” function. Room temperature change in save operation by “10°C heat” function.

ii) Allowing heating operation even at outside temperature –15°C by improving heating performance at low outside temperature

By providing refrigerant evenly to heat exchanger and considerably increasing maximum refrigerant circulation with adoption of Φ5mm thin diameter high density heat exchanger and high performance inverter rotary compressor, heating operation is made possible even at outside temperature –15°C during mid winter.

3. Convenient functions (option)

i) “External signal control” and “operation signal pickup” functions

“Start/Stop” function by external signal and “operation signal pickup” function to external signal are provided as option.

ii) Wired remote controller

Wired remote controller is available as option.

Main specifications / Time of release / Production quantity (first year)

Main specifications (indoor unit)

Model name		Indoor unit
Model name		ASYAO7LBCM	ASYAO9LBCM	ASYA12LBCM
Power supply	V / Φ / Hz	230 / 1 / 50	230 / 1 / 50	230 / 1 / 50
Cooling capacity (Max)	kW	2.1 (2.7)	2.5 (3.2)	3.5 (3.7)
Heating capacity (Max)	kW	2.7 (3.3)	3.3 (4.2)	4.0 (4.8)
Dimension (H x W x D)	mm	260 x 790 x 198
Weight	kg	7.5
Combination of connectable indoor units		07 + 07, 07 + 09, 07 + 12, 09 + 09, 09 + 12 total 5 combinations

Main specifications (outdoor unit)

Model name		Outdoor unit (AOYA14LAC2)
Model name		Indoor unit (ASYA07LBCM + ASYA07LBCM)
Power supply	V / Φ / Hz	230 / 1 / 50
Cooling capacity (Max)	kW	4.0 (4.4)
Heating capacity (Max)	kW	4.4 (5.4)
Energy consumption efficiency (cooling operation)	kW / kW	3.67
Energy consumption efficiency (cooling operation)	kW / kW	4.27
Dimension (H x W x D)	mm	540 x 790 x 290
Weight	kg	37

Time of release/Production quantity

Time of release	middle of April, 2009
Production quantity (First year: Outdoor unit basis)	10,000 units

Note

*1 Industry's top class :: As of March 26, 2009 and according to our company's survey.

Contents (Prices, Specifications and Contacts etc.) in each release are at the time of release.
These contents are subject to change without prior notice.
