AIRSTAGE SINGLE-ROOM MINI-SPLIT SYSTEMS Wall Mounted RLF/RLX Series Extra Low Temp Heating 18RLXFWH

XLTH; Extra Low Temperature Heating

Indoor Unit Systems: ASU18RLXFW, Outdoor Unit: AOU18RLXFWH

Indoor Unit:
ASU18RLF
Outdoor Unit:
AOU18RLXFWH
Downloads:
Operation Manual
Warranty
SEER of 20
  • INVERTER 7 year compressor 5year parts Warranty. Refrigerant R410A ENERGY STAR®

  • Inverter Technology
  • ENERGY STAR® Qualified
  • Clean Air
  • Quiet Operation
  • Wireless Remote Controller
  • Washable Panel Filter
  • Smart System: Auto Mode
  • Humidity Control

Cooling  18,000 BTU/h
Heating  21,600 BTU/h

Specification
Power Source Voltage/Frequency/Phase 208-230/60/1
Capacity Cooling BTU/h 18,000(7,000~23,000)
Heating 21,600(7,000~29,000)
HSPF BTU/hW 10.0
SEER BTU/hW 19.2
EER Cooling/Heating W/W 5~75 (-15~24)
Operation Range Cooling °F(°C) 14~115 (-10~46)
Heating 5~75 (-15~24)
Moisture Removal Pt./h(l/h) 5.9 (2.8)
MAX.CRT.BKR A 20
Air Circ. C.F.M. Hi (m³/h) 541 (920)
Medium 435 (740)
Low 365 (620)
Quiet 306 (520) Clg
318 (540) Htg
Noise Level Hi dB(A)
15RLS3
43/44
Medium 37/37
Low 33/33
Quiet 28/28
Outdoor Fan Speed RPM 620/620
Outdoor Noise Level dB(A)
Clg/Htg
47/50
Current Cooling A 6.2/13.5
Heating 8.0/14.5
Power Use Cooling kw 1.35/3.01
Heating 1.80/3.23
Fan Speeds Stage 4+Auto
Air Direction Horizontal Automatic
Vertical Automatic
Air Filter Washable
Apple Catechin Filter Yes
Connection Method Flare
Combined Min.Lgth Ft (m) 16 (5)
Max.Lgth 164 (50)
(pre-charge: 66’)
Max. Vertical Diff. Ft (m) 98 (30)
Conn. Pipe Diameter Indoor Inch Suc. 5/8#
Outdoor Dis. 3/8#
Net Weight Indoor lbs.(kg) 31 (14)
Outdoor 135 (61)
Dimensions Height Indoor Inch 12-5/8
mm 320
Outdoor Inch 32-3/4
mm 830
Width Indoor Inch 39-1/4
mm 998
Outdoor Inch 35-3/8
mm 900
Depth Indoor Inch 9
mm 228
Outdoor Inch 13
mm 330
Refrigerant (Global Warming Potential) R410A
Scroll
Dimensions

Indoor Unit: ASU18RLXFW

Indoor Units: Dimensions

Outdoor Unit: AOU18RLXFWH

Outdoor Units: Dimensions
